Title
Installing Upper Motor Rotor
Creator
Goll Studio
Identifier
MSP33.B002.F06.I07
Source Identifier
MSP33.B002.F06.I07
Description
Construction workers installing a new drive motor rotor during the major expansion project to increase steel production at Jones & Laughlin Steel Corporation’s Aliquippa Works. A new 44-inch blooming mill and its drive were installed, replacing a steam-engine drive mill that set many production records during its time. The installation process was accomplished in the remarkable time of 7 days and 14 1/2 hours of down-time. The 44-inch blooming mill was driven by four 3000-hp, 70 to 140-rpm, 750-volt, double-armature motors, arranged in tandem twin drive. The main drive motors, motor-generator sets, controls, and switchgear were all housed in a 191 foot by 68 foot motor room, which included a down-draft recirculating ventilation system. The 44-inch Blooming Mill was shut down in October 1984.
Genre
photographs
Subject
Jones & Laughlin Steel Corporation.Aliquippa Works.44-inch Blooming Mill.
Steel industry and trade--Pennsylvania--Aliquippa.
Construction workers--Pennsylvania--Aliquippa.
Electric motors--Pennsylvania--Aliquippa.
Rotors.
Source
Jones & Laughlin Steel Corporation Collection Photographs, 1864-1953, MSP 33, Library and Archives Division, Senator John Heinz History Center
Contributor
Detre Library & Archives, Heinz History Center
Collection
Jones & Laughlin Steel Corporation Photographs
